In this section we are presenting examples of Unigraphics
advertisements as well as a few magazine covers that featured Unigraphics
images. Note that this collection does not represent all of the advertisements
placed by the Unigraphics organization over the years, however it is a
representative sample.
Machine Design, February, 1981
Industry Week, April, 1985
Industry Week, September, 1985
Design News, November, 1985
Machine Design, November, 1985
Machine Design Cover, February, 1986
The cover story was about mechanical simulation using
kinematics analysis and graphical simulation. The cover picture is
from a dynamic simulation of a typewriter print ball mechanism using Unigraphics
running on the D-2300.
Computer-Aided Engineering Cover, June, 1986
Another cover story on mechanical simulation and analysis.
This time the cover image was of the results of a 4-bar mechanism kinematics
analysis using Unigraphics Mechanism module.
Industry Week, March, 1987
Computer-Aided Engineering, June, 1992
Machine Design Cover, August, 1995
On this cover included a UG/Photo image supplied by 3M
Corp showing a portion of a film production machine.
Computer-Aided Engineering, November, 1995
Computer-Aided Engineering Cover, May, 1996
Computer-Aided Engineering, August, 1996
Computer-Aided Engineering, February, 1997
Computer-Aided Engineering, September, 1998
Machine Design, December, 1998
Desktop Engineering, February, 1999
Desktop Engineering, April, 1999
Desktop Engineering, August, 1999
Desktop Engineering, February, 2000
Desktop Engineering, September, 2000
Desktop Engineering, September, 2001
Computer-Aided Engineering, October, 2001
