GRIP II Specification (circa 1977).
United Computing UG Training Certificate (circa 1977)
United Computing GRIP Training Certificate (circa
1978)
Unigraphics development organization chart (circa 1979).
Memo announcing the merging of United Computing into
McAuto.
Sample of punch cards used by McAuto
These punched cards were used as the primary means
of programming Unigraphics during the 70's and well into the 80's.
In fact, the archived copies of the source code was routinely stored on
punched cards due to the fact that it was the most stable media available
at the time. The last of the Unigraphics punch card based archives
were not disposed of until after the EDS acquisition in 1991 and the Cypress
facility was moved to the present location in 1992.
Price quote for a DEC PDP-11/70 system.
Note that this CPU could support 4 to 6 Unigraphics
stations (the price above did NOT include the Unigraphics design stations
nor the Unigraphics software, also note the estimated delivery schedule,
things have sure changed haven't they?).
Unigraphics development organization chart (circa
1980).
Unigraphics I Data Definition (circa 1981)
This manual contains a complete set of entity descriptions,
and their part file data formats, for Unigraphics I. The significance
of this document is that it represents the last revenue generated by Unigraphics
I earned by the Unigraphics organization. In 1992 (hence the reason
for the EDS logo added to the document pages) this manual was sold and
a license was given to a company creating a translator to read Unigraphics
I part files. This was a one time license as the translator was going
to be used to process the archive files for one customer only.
Movie Script for the Unigraphics promotional movie,
"Doorway to Growth" (circa 1982)
This movie, which had a very slick ending scene was sometimes
called the "Smoking Door" since that last scene had the "star" walking
into the "future" by stepping through a modern "Star Trek" like door with
a lot of stage smoke seen just beyond.
The A1 Tool benchmark part (aka, the "Ashtray")
McAuto Name Plate
Name plates like these were provided for all of the McAuto
sales offices in the 80's. This particular one came from the Chicago,
IL office.
GRIP Programming Manual
Souvenir from the GM/EDS benchmark
Paul Sickings Shamrock Presentation
Unigraphics development organization chart (circa
1988).
Cover sheet of the V10.0 Development Release Plan.
The famous V9 to V10 Transition Guide
1997 GST Agenda
The autograph on the cover of this agenda belongs to Jackie
Stewart of Formula 1 fame.
SEC Form S-1 (Registration for Public Offering) for
Unigraphics Solutions, Inc.
Unigraphics Solutions Inc. IPO Prospectus
Unigraphics Solutions 1998 Annual Report
Unigraphics Solutions 1999 Annual Report
UGS 2000 Annual Report
EDS Tender Offer for UGS Shares, September 2001
